RJY 1.3 inch 240*240 TFT Smart Watch Touch Screen LCD Display
Model Name: RV069LFM-350-40
LCD Type: 6.9-inch TFT LCD display
Resolution: 280*1424
Viewing Angle: Full wide viewing angle (IPS)
Brightness: TBD (To be determined)
Driver IC: ST7703I
Interface: MIPI
Active Area: 33.60 (H)*170.88 (V)
Operating Temperature: -20℃~ +70℃
Storage Temperature: -30℃~ +80℃
Product Description
This display is designed to transform visual experiences with its unique stretched bar design, offering a perfect blend of aesthetics and functionality for diverse applications.
Product Features
1. Innovative Stretched Bar Design: The 6.9-inch stretched bar form factor introduces a new dimension to displays, making it an ideal choice for applications where space optimization and visual innovation are crucial.
2. Vivid Visuals with High Resolution (280*1424): Immerse yourself in stunning visuals with the high-resolution display, ensuring clarity and precision in showcasing content across a diverse range of applications.
3. Full Wide Viewing Angle (IPS): Embrace consistent and vibrant colors from any viewing angle, courtesy of Full Wide Viewing Angle (IPS) technology, enhancing the overall user experience.
4. Adaptive Brightness (TBD): The display's brightness, yet to be determined, adapts dynamically to ambient light conditions, ensuring optimal visibility and readability in varying environments.
5. MIPI Interface with ST7703I Driver IC: The combination of MIPI interface and ST7703I driver IC provides a robust and high-speed connection, facilitating seamless data transfer and ensuring smooth, responsive interactions for your electronic projects.
|
Model |
RV069LFM-350-40 |
|
LCD size |
6.90 inch TFT bar lcd display panel |
|
Display Mode |
Normally Black |
|
Resolution |
280(RGB)x1424 |
|
Pixel pitch |
40(H) x3 x 120(V) |
|
Pixel Arrangement |
RGB Vertical Stripe |
|
Viewing direction |
ALL |
|
Module outline dimension |
38.20 (H)*181.47(V)*3.40(D) |
|
LCD AA |
33.60 (H)*170.88 (V) |
|
Colors |
16.7M |
|
Driver IC |
ST7703I |
|
Interface |
MIPI |
|
Backlight |
White LED |
|
Operating Temperature |
20℃~ +70℃ |
|
Storage Temperature |
30℃~ +80℃ |
|
Pin |
40pin |
