2.8 INCH 240*320 TFT LCD DISPLAY With SPI Interface
Model Name: RV028QVP-350-10
LCD Type: 2.8-inch TFT LCD display
Resolution: 240*320
Viewing Angle: Full wide viewing angle (IPS)
Brightness: TBD (To be determined)
Driver IC: ST7789
Interface: SPI
Touch IC: FT6336U
Touch structure: G+F
Operating Temperature: -20℃~ +70℃
Storage Temperature: -30℃~ +80℃
Product Description
Unveiling the RJY 1.69 Inch 240*280 TFT LCD Display, featuring the model name RV028QVP-350-10.
This display, with a 2.8-inch TFT LCD type and a resolution of 240320, is designed to deliver exceptional visual performance in a compact form factor.
With advanced features and a versatile interface, it caters to a wide range of electronic applications.
Product Features
1. Compact Form Factor: Despite its 2.8-inch size, this display offers a high resolution of 240*320, providing clear and vibrant visuals within a compact design.
2. Full Wide Viewing Angle (IPS): Leveraging Full Wide Viewing Angle (IPS) technology, the display ensures excellent visibility from various angles, enhancing user experience across different scenarios.
3. Driver IC - ST7789: Equipped with the reliable ST7789 driver IC, the display guarantees smooth and stable performance, delivering high-quality graphics and images.
4. SPI Interface: The SPI interface provides a versatile and customizable connection, allowing seamless integration into a variety of electronic projects with specific requirements.
5. Advanced Touch Technology: Featuring the FT6336U touch IC and a G+F touch structure, this display provides an advanced and responsive touch experience, enhancing user interaction in applications that require touch input.
|
Model |
RV028QVP-350-10 |
|
Size |
2.8 inch TFT LCD module |
|
Display Mode |
Normally Black |
|
Resolution |
240(RGB)x320 |
|
Pixel pitch |
0.18(H) x 0.18(V) |
|
Pixel Arrangement |
RGB Vertical Stripe |
|
Viewing direction |
ALL |
|
Module outline dimension |
50 (H)*69.02 (V)*2.30(D) |
|
LCD AA |
43.2 (H)* 57.6 (V) |
|
TP VA |
43.6 (H)* 58.05 (V) |
|
Colors |
16.7M |
|
Driver IC |
ST7789 |
|
Interface |
SPI |
|
Backlight |
White LED |
|
Touch IC |
FT6336U |
|
Surface hardness |
6H |
|
Touch structure |
G+F |
|
Operating Temperature |
-20℃~ +70℃ |
|
Storage Temperature |
-30℃~ +80℃ |
