RJY 21.5 inch 1920*1080 TFT LCD Display Screen with HDMI Board
Model Name: RV215FHM-300-30
LCD Type: 21.5-inch TFT LCD display
Resolution: 1920*1080
Viewing Angle: Full wide viewing angle (IPS)
Brightness: 300/500nit
Display Color: 16.7M
Interface: LVDS
Brightness: TBD (To be determined)
Display area: 478.656(H) x 260.28 (V)
Operating Temperature: -20℃~ +70℃
Storage Temperature: -30℃~ +80℃
Product Description
The RJY 21.5 Inch 1920*1080 TFT LCD Display Screen is a testament to cutting-edge visual technology. This expansive display redefines clarity and brilliance, making it the perfect canvas for various applications demanding superior image quality.
Product Features
1. Full HD Resolution (1920*1080): Immerse yourself in a world of detail and clarity with the Full HD resolution, offering crisp and sharp visuals for a heightened viewing experience.
2. Adaptive Brightness (300/500nit): The display's brightness adapts dynamically to ambient lighting conditions, ensuring optimal visibility in various environments, from well-lit rooms to low-light settings.
3. Vivid Color Palette (16.7M): Experience a rich and vibrant color spectrum of 16.7 million, ensuring that images, videos, and graphics are displayed with lifelike precision and accuracy.
4. Full Wide Viewing Angle (IPS): Whether viewed from the center or at an angle, the IPS technology guarantees consistent and vivid visuals, making it suitable for collaborative work and shared viewing experiences.
5. Efficient LVDS Interface: The LVDS interface ensures efficient and high-speed data transfer, allowing seamless connectivity with a variety of devices and systems for versatile applications.
|
Model |
RV215FHM-300-30 |
|
Size |
21.5 inch TFT LCD Panel |
|
Pixels |
1920(H) x3(RGB)x 1080 (V) |
|
Active Area [mm] |
478.656(H) x 260.28 (V) |
|
Pixel Pitch [mm] |
0.0831(H) x 0.241 (V) |
|
Outline Dimension |
495.64(H) x 292.21(V) x9.85(D) |
|
Display Mode |
IPS(Normal Black) |
|
Pixel arrangement |
RGB Vertical stripe |
|
Luminous |
495.6*292.2*10.3 |
|
Brightness |
TYP=300 /500 cd/㎡ |
|
Interface |
LVDS |
|
Storage Temperature |
-20-60 ºC |
|
Operating Ambient Temperature |
-10-50 ºC |
|
LED Current |
220 mA |
|
LED Voltage |
43 v |
|
Viewing Angle |
89/89/89/89 |
