Rongjiayi-High-tech LCD display manufacturer with research, development, design since 2014.
RJY 23.8 inch 1920*1080 30pin LVDS Interface TFT LCD Display Module
Model Name: MV238FHM-N30
LCD Type: 23.8-inch TFT LCD display
Resolution: 1920*1080
Viewing Angle: Full wide viewing angle (IPS)
Brightness: 250nit
Interface: LVDS
Operating Temperature: 0℃~ +50℃
Storage Temperature: -20℃~ +60℃
Product Description
This specification applies to the 23.8 inch- wide Color a-Si TFT-LCD Module. The display supports the FHD – 1920(H) x 1080(V) screen format and 16.7M colors (8-bit RGB data input). The input interface is Dual channel LVDS and this module doesn’t contain an
driver board for backlight.
Product Features
1. High-Resolution Visuals (1920*1080): Enjoy a feast for the eyes with a high-resolution display of 1920*1080 pixels on the generous 23.8-inch screen, delivering crisp and detailed images.
2. Full Wide Viewing Angle (IPS): Experience consistent and vibrant visuals from any angle with IPS technology, making it ideal for collaborative work environments and interactive displays.
3. Adaptable Brightness (250nit): The panel offers an adaptable brightness of 250nit, ensuring clear visibility while catering to different lighting conditions for versatile use.
4. Efficient LVDS Interface: With an LVDS interface, the display panel ensures efficient and high-speed data transmission, facilitating seamless connectivity with a variety of devices and systems.
5. Operational Versatility: Designed to operate in a temperature range from 0℃ to +50℃, this display panel is versatile and reliable, suitable for a wide range of applications across different industries and settings.
|
Model |
MV238FHM-N30 |
|
Size |
23.8 inch tft lcd module |
|
Active Area |
527.04(H) x 296.46(V) |
|
Resolution |
1920*1080 |
|
Pixel Pitch |
274.5(per one triad)×274.5 |
|
Pixel Arrangement |
R.G.B. Vertical Stripe |
|
Display Mode |
Normally Black |
|
White Luminance |
250 (Typ.) |
|
Contrast Ratio |
3000(Typ.) |
|
Outline Dimension |
543.0(H) x 317.4(V) x 11.2(D) (Typ.) |
|
Electrical Interface |
Dual channel LVDS,8-bits RGB data input |
|
Support Color |
16.7M colors |
|
Surface Treatment |
SAG 40%, 3H |
|
Operating Temperature |
0 to +50 |
|
Storage Temperature |
-20 to +60 |
